⏱️ H3Y-4 Timer with PYF14A Socket – 4PDT Power ON Delay Relay
⏱️ H3Y-4 Timer with PYF14A Socket – 4PDT Power ON Delay Relay
Regular price
GH₵125.00
Regular price
GH₵170.00
Sale price
GH₵125.00
Unit price
/
per
Couldn't load pickup availability
Model: H3Y-4
Socket Included: PYF14A (14-pin DIN rail/screw mount)
Brand: Omron
Function: Power ON-delay timer with 4PDT output
🔧 Key Features
- Time Range: 0.1 seconds to 3 hours (selectable via dial)
- Operation Mode: Power ON-delay with self-reset
- Output Contacts: 4PDT (Four Pole Double Throw)
- Mounting Style: Plug-in with PYF14A socket (DIN rail or screw mount)
- Status Indicators: LED for power and output status
- Case Color: Beige or black (depending on variant)
⚙️ Technical Specifications
|
Parameter |
Value |
|---|---|
|
Rated Voltage |
12, 24, 48, 125 VDC / 24, 100–240 VAC |
|
Contact Rating |
3A at 250 VAC (resistive load) |
|
Minimum Load |
1 mA at 1 VDC |
|
Time Accuracy |
±1% full scale |
|
Reset Time |
Max. 0.1 s |
|
Ambient Temp. Range |
-10°C to 50°C |
|
Humidity Range |
35% to 85% RH |
|
Insulation Resistance |
100 MΩ min. at 500 VDC |
|
Dielectric Strength |
2,000 VAC for 1 min |
|
Vibration Resistance |
10–55 Hz, 0.75 mm amplitude |
|
Shock Resistance |
1,000 m/s² (destruction), 100 m/s² (malfunction) |
|
Enclosure Rating |
IP40 |
|
Weight (with socket) |
Approx. 90 g |
🧩 PYF14A Socket Highlights
- Type: 14-pin front-connecting socket
- Mounting: DIN rail or screw mount
- Terminal Style: Screw terminals with secure clamping
- Material: Flame-retardant resin
- Torque Spec: 0.78 to 1.18 N·m for terminal screws
✅ Applications
- Industrial automation and control panels
- Sequential machine operations
- Delay-based switching systems
- HVAC and lighting control circuits
