12A 3-Pole Contactor – Schneider Electric TeSys D LC1D12P7, 3NO, 230V AC Coil, AC-3 Rated, Up to 440V
GH₵400.00
GH₵500.00
Pickup currently not available
Short Description:
Reliable and compact 3-pole contactor rated 12A, equipped with a 230V AC coil. Ideal for motor control applications up to 5.5 kW in AC-3 duty at 400/415V.
Full Product Description:
The LC1D12P7 is a high-performance 3-pole contactor from Schneider Electric’s TeSys D series, built for dependable switching of motors and electrical loads in commercial and industrial settings. With a rated operational current of 12A (AC-3) and 3 normally open (3NO) contacts, this unit is well-suited for motors up to 5.5 kW at 400/415V.
It features a 230V AC control coil and supports voltages up to 440V, making it ideal for a wide range of control panels, automation systems, and power circuits. The TeSys D range offers compact size, easy integration with accessories, and long mechanical and electrical life.
Technical Specifications:
| Attribute | Specification |
|---|---|
| Product Code | LC1D12P7 |
| Series | TeSys D |
| Rated Operational Current (AC-3) | 12A |
| Motor Rating (AC-3) | Up to 5.5 kW @ 400V |
| Poles and Contacts | 3P (3NO) |
| Control Coil Voltage | 230V AC |
| Operational Voltage | Up to 440V |
| Utilization Category | AC-3 |
| Mounting Type | DIN Rail or Panel Mount |
| Conformity | IEC 60947-4-1 |
| Mechanical Durability | 10 million operations |
| Electrical Durability | 1.5 million operations (AC-3) |
Applications:
✔ Motor starters and protection
✔ Pumps, fans, and compressors
✔ HVAC equipment
✔ Industrial automation panels
