18A 3-Pole Contactor – Schneider Electric TeSys D LC1D18P7, 3NO, 230V AC Coil, AC-3 Rated, Up to 440V
GH₵520.00
GH₵600.00
Pickup currently not available
Short Description:
Durable 3-pole contactor with 230V AC coil, rated 18A for AC-3 applications. Suitable for motor control up to 7.5 kW at 400/415V.
Full Product Description:
The LC1D18P7 from Schneider Electric’s TeSys D series is a rugged and compact 3-pole contactor designed for efficient switching of motors and electrical loads. With a rated operational current of 18A (AC-3) and 3 normally open (3NO) contacts, it supports motor loads up to 7.5 kW at 400/415V.
This contactor is fitted with a 230V AC coil and handles operational voltages up to 440V. Its space-saving design and robust performance make it ideal for use in motor starters, HVAC systems, and industrial automation panels. It conforms to IEC 60947-4-1, ensuring reliable operation and long service life.
Technical Specifications:
| Attribute | Specification |
|---|---|
| Product Code | LC1D18P7 |
| Series | TeSys D |
| Rated Operational Current (AC-3) | 18A |
| Motor Rating (AC-3) | Up to 7.5 kW @ 400V |
| Poles and Contacts | 3P (3NO) |
| Control Coil Voltage | 230V AC |
| Operational Voltage | Up to 440V |
| Utilization Category | AC-3 |
| Mounting | DIN Rail / Panel Mount |
| Standard Compliance | IEC 60947-4-1 |
| Mechanical Durability | 10 million operations |
| Electrical Durability | 1.5 million operations (AC-3) |
Applications:
✔ Motor control up to 7.5 kW
✔ HVAC systems
✔ Pumps and fans
✔ Commercial and industrial control panels
