38A 3-Pole Contactor – Schneider Electric TeSys D LC1D38P7, 3NO, 230V AC Coil, AC-3 Rated, Up to 440V
GH₵1,200.00
GH₵1,500.00
Pickup currently not available
Short Description:
Heavy-duty 3-pole contactor with 230V AC coil, rated 38A for AC-3 motor control. Ideal for motors up to 18.5 kW at 400/415V.
Full Product Description:
The LC1D38P7 from the Schneider Electric TeSys D series is a high-performance 3-pole contactor designed for reliable motor control in industrial applications. It features 3 normally open (3NO) contacts and is rated for 38A (AC-3), supporting motor loads up to 18.5 kW at 400/415V.
The contactor includes a 230V AC control coil and is suitable for operational voltages up to 440V. With high electrical and mechanical durability, the LC1D38P7 is a preferred choice for engineers and panel builders needing compact, DIN rail–mountable solutions for frequent switching of motors and resistive loads.
Technical Specifications:
| Attribute | Specification |
|---|---|
| Product Code | LC1D38P7 |
| Series | TeSys D |
| Rated Operational Current (AC-3) | 38A |
| Motor Rating (AC-3) | Up to 18.5 kW @ 400V |
| Contact Configuration | 3P (3NO) |
| Control Voltage | 230V AC Coil |
| Max Operating Voltage | 440V |
| Utilization Category | AC-3 |
| Mounting Type | DIN Rail / Panel |
| Mechanical Durability | 10 million operations |
| Electrical Durability | 1.5 million operations (AC-3) |
| Standards | IEC 60947-4-1 |
Applications:
✔ Motor control up to 18.5 kW
✔ Pumps, fans, compressors
✔ HVAC systems
✔ Control panels and automation systems
