Chint NXB-63 2P C10 Miniature Circuit Breaker – 10A, 6kA Breaking Capacity, Type C Curve, Double Pole MCB for Low-Load Single-Phase Protection

Product Code: NXB-63-2P-C10
Brand: Chint
Product Type: Miniature Circuit Breaker (MCB)
Pole Configuration: 2 Pole (2P)
Rated Current: 10 Amperes (10A)
Tripping Curve: Type C
Breaking Capacity: 6kA
Standard Compliance: IEC/EN 60898-1
Mounting Method: DIN Rail

Product Overview

The Chint NXB-63 2P C10 MCB is a compact, reliable double-pole circuit breaker engineered to provide simultaneous protection of live and neutral conductors in single-phase circuits. Rated at 10A, it is ideal for low-load applications like lighting circuits, control panels, and general-purpose socket protection where moderate inrush currents may occur.

With a Type C tripping characteristic and a 6kA breaking capacity, this MCB ensures dependable disconnection during overloads and short circuits, enhancing safety in both residential and commercial electrical systems.

Key Features

• 🔹 10A Rated Current – Perfect for lighting, receptacles, and low-consumption equipment.

• ⚡ 6kA Fault Protection – Handles significant short-circuit currents without failure.

• 🔄 Type C Tripping Curve – Withstands moderate inrush currents from devices like LED drivers or small motors.

• 🔌 2P Switching – Disconnects both phase and neutral simultaneously for complete isolation.

• 🧲 DIN Rail Compatible – Designed for quick and easy installation in all standard panel boards.

• ✅ Tested to IEC/EN 60898-1 – Ensures international safety and quality compliance.

Technical Specifications

Typical Applications

• Lighting and general-purpose socket circuits

• Protection of residential circuits with small appliances

• Low-load branch circuits in commercial boards

• HVAC and lighting control systems

• Backup circuits from small inverters or UPS

Why Choose Chint NXB-63 2P C10?

The NXB-63 2P C10 MCB offers dual-pole protection, making it ideal for installations where complete disconnection of live and neutral is required for added safety. With Chint’s trusted performance and certification to global standards, it’s the preferred choice for compact, low-current protection in professional-grade systems.
