Delta DRL-24V75W1AZ – 24V DC 75W 3.125A DIN Rail Power Supply

Delta DRL-24V75W1AZ – 24V 75W DIN Rail Power Supply

The Delta DRL-24V75W1AZ is a compact and efficient DIN rail power supply, designed for industrial automation and control applications. With universal AC input voltage, it ensures stable power delivery and high efficiency for various systems.

Key Features:

• Output Voltage: 24V DC
• Output Power: 75W
• Output Current: 3.125A
• Input Voltage Range: 85-264V AC / 120-375V DC
• Efficiency: Up to 89%
• Operating Temperature: -20°C to +70°C (with derating)
• Protection Features: Overload, overvoltage, and short circuit protection
• Mounting Style: DIN Rail Mount
• Compact Dimensions: 123.6mm (H) x 27mm (W) x 102mm (D)
• Weight: 0.22 kg (0.49 lb)

Ideal for industrial automation, control panels, and embedded systems, the Delta DRL-24V75W1AZ offers reliable performance, energy efficiency, and easy installation.
