Delta DVP16HP11R – Slim 8DI/8DO Extension Relay Module

The Delta DVP16HP11R is a compact digital I/O extension module, designed for expanding the functionality of Delta DVP series PLCs. With eight digital inputs and eight relay outputs, it ensures reliable switching and control for industrial automation applications.

Key Features:

• Input Type: 8 Digital Inputs
• Output Type: 8 Relay Outputs
• Supply Voltage: 24V DC (-15% ~ 20%)
• Power Consumption: 2W
• Fuse Capacity: ES: 2A/250V AC, SV: 2.5A/30V DC
• Program Capacity: 4k Steps
• Response Time: 10ms
• Noise Immunity: ESD: 8 kV Air Discharge, EFT: Power Line 2 kV, Digital I/O 1 kV
• Insulation Impedance: >5 MΩ (all I/O points to ground: 500V DC)
• Operating Temperature: 0°C to +55°C
• Storage Temperature: -25°C to +70°C
• Mounting Type: DIN Rail

Ideal for expanding PLC control capabilities, the Delta DVP16HP11R offers stable performance, easy integration, and enhanced automation flexibility
