EZ9F56220 – Schneider Easy9 Miniature Circuit Breaker 20A, 2 Pole, C Curve, 6000A Breaking Capacity

Product Description
The Schneider Electric EZ9F56220 Easy9 Miniature Circuit Breaker (MCB) delivers reliable protection against overloads and short circuits in dual-phase residential circuits. With a 20A rating and C-curve tripping characteristic, it’s ideal for lighting, socket outlets, and small appliances.

Key Features:
•     Rated Current: 20A for medium-load circuits
•     Poles: 2P (two protected poles)
•     Curve Type: C Curve, suitable for resistive and inductive loads
•     Breaking Capacity:
•     10,000A at 220V AC (Icn)
•     6,000A at 400V AC (Icn)
•     Trip Technology: Thermal-magnetic mechanism for dual-mode protection
•     Voltage Range: 220V AC / 400V AC, 50/60 Hz
•     Magnetic Tripping Limit: 5 to 10 × In
•     Insulation Voltage: 500V AC
•     Impulse Withstand Voltage: 4kV
•     Isolation Capability: Fully compliant with IEC/EN 60898-1
•     Environmental Compliance: RoHS and REACH certified
•     Eco Packaging: Made with minimum 70% recycled cardboard
•     Carbon Footprint: Total lifecycle impact rated at 39 units

Applications: The EZ9F56220 is ideal for residential distribution boards requiring dual-pole protection. It’s suited for lighting circuits, socket outlets, and small appliances in split-phase systems. Its compact design and unified terminal layout simplify installation and maintenance.

Why Choose Easy9? Schneider Electric’s Easy9 series is known for its safety, simplicity, and sustainability. The EZ9F56220 offers robust protection, clear wiring indicators, and a durable build—making it a reliable choice for electricians and homeowners.
