H3Y-4 – 24VDC Time Delay Relay

Supply Voltage: 24V DC Mounting: 14-pin plug-in (DIN 48 × 48 mm)
Output Type: 4PDT (4 Form C) relay contact Time Range: Model-dependent (e.g., 0.5–10s, 2–60s, 3h, etc.)

Key Specifications:

• Time Delay Mode: ON-delay (Power ON start)
• Contact Rating: 3A @ 250V AC / 30V DC (resistive load)
• Power Consumption: Approx. 0.9W
• Reset Voltage: ≥10% of rated supply voltage
• Accuracy:
• Operating time: ±1% FS max.
• Setting error: ±10% FS ±50 ms
• Voltage/temperature influence: ±2% FS max.
• Reset Time: ≤0.1s
• Ambient Temp: -10°C to +50°C
• Humidity: 35–85% RH (non-condensing)
• Insulation Resistance: ≥100 MΩ @ 500V DC
• Dielectric Strength: 2000V AC between power and output terminals
• Vibration/Shock Resistance: 10–55 Hz, 0.5 mm amplitude / 100 m/s²
• Life Expectancy:
• Electrical: ≥200,000 operations
• Mechanical: ≥10 million operations
• Enclosure Rating: IP40 (front panel)
• Weight: Approx. 50g
• Compatible Sockets: PYF14A, PYF14A-N, PYF14A-E

Features:

• Precise analog dial for time setting
• LED indicators for power and output status
• Compact design for space-saving panel integration
• Long mechanical and electrical life
• Ideal for use in control panels, conveyors, HVAC, and safety interlocks
