KCD1-101 Sub-Miniature 2-Pin SPST ON-OFF Rocker Switch, Snap-In Panel Mount, 6A 125VAC / 3A 250VAC, Non-Illuminated

Name: KCD1-101 Sub-Miniature 2-Pin SPST ON-OFF Rocker Switch, Snap-In Panel Mount, 6A 125VAC / 3A 250VAC, Non-Illuminated
Brand: Electrical Supplies Ghana
Price: 9.00 GHS
Availability: InStock

GH₵9.00

~~GH₵15.00~~ GH₵9.00

Sale Sold out

Quantity

Detailed Descriptio

The KCD1-101 is a widely used, sub-miniature rocker switch providing simple two-position, latching ON-OFF functionality. It features a Single Pole Single Throw (SPST) contact configuration, making it a straightforward choice for basic power control applications. It is non-illuminated and designed for quick, tool-free installation using a snap-in panel mount mechanism.

Key Specifications

Model: KCD1-101 (also commonly referred to as KCD1-1N by some manufacturers)

Operation: 2-Position, Latching ON-OFF
Contact Configuration: SPST (Single Pole Single Throw)
Terminals: 2 Pins (brass quick-connect terminals)
Electrical Rating: 6A at 125VAC; 3A at 250VAC (Check specific product for potential 10A/6A variants)
Contact Resistance: 50mΩ maximum
Insulation Resistance:

$is greater than or equal to$

100MΩ (500VDC)
Dielectric Strength: 1500VAC for 1 minute
Electrical Life:

$is greater than or equal to$

10,000 Cycles
Housing Material: Durable Nylon 66 (Standard Black)
Mounting Style: Snap-in panel mount (Typically fits a 13.2mm x 19.2mm rectangular cutout)
Certifications: CE, CQC, SGS certified
Applications:

This is an essential component for basic power switching in small appliances, computer peripherals, medical equipment, power strips, and various electronic devices where a simple, reliable switch is needed.
