Omron H3DT-HDS AC200-240V OFF-Delay DIN Rail Timer Relay SPDT 0.1-12 s

The Omron H3DT-HDS AC200-240V OFF-Delay Timer Relay is a reliable industrial DIN rail mounted timing device designed for automated control systems and control panels. This robust timer supports a wide supply voltage range of 200–240 VAC and offers power OFF-delay functionality with adjustable timing between 0.1 s and 12 s across two selectable ranges, making it ideal for sequencing and delay control in machinery and process automation. It features a single SPDT (1 Form C) relay output and Push-In Plus terminal technology for quick and secure wiring, helping to reduce panel build time and improve installation efficiency. Compact and energy-efficient, the H3DT-HDS enhances performance and reliability in industrial and OEM applications.

📌 Key Specifications

• Model: H3DT-HDS AC200-240V

• Function: OFF-Delay timer relay (power OFF delay)

• Supply Voltage: 200 V to 240 VAC 50/60 Hz

• Timing Range: 0.1 s to 12 s (2 ranges)

• Output: SPDT (1 Form C) relay

• Mounting: DIN rail

• Terminal Type: Push-In Plus terminal block

• Applications: Industrial automation, delay control, sequencing, machine timing systems

Add dependable timing control to industrial automation panels with the Omron H3DT-HDS, designed for performance, space-saving installation, and precise delay operations.
