Phoenix Contact ESSENTIAL-PS/1AC/24DC/480W/EE – 24 V DC / 480 W Single-Phase DIN-Rail Power Supply (Item 2910588)

Phoenix Contact ESSENTIAL-PS/1AC/24DC/480W/EE – 24 V DC / 480 W Single-Phase DIN-Rail Power Supply (Item 2910588)

GH₵3,000.00
GH₵3,500.00 GH₵3,000.00
Sale Sold out

Detailed Description:
The Phoenix Contact ESSENTIAL-PS/1AC/24DC/480W/EE (Article No. 2910588) is a high-performance industrial power supply unit designed for single-phase input and a robust 24 V DC output capacity of up to 480 W. It’s built for DIN-rail mounting in control cabinets, automation panels and demanding industrial environments.

Features & Highlights:

  • Single-phase input: 100–240 V AC nominal, 85–264 V AC operational.

  • Also accepts DC input range: 120–375 V DC.

  • Output: 24 V DC (±2 %) with up to 20 A current (i.e., 480 W power).

  • Setting range for output voltage: 22–28 V DC when output power up to 480 W.

  • High efficiency: ~85 % at 115 V AC, ~88 % at 230 V AC.

  • Compact width: 85.5 mm; height: 123.6 mm; depth: 128.5 mm (for installation planning).

  • Mounts easily on DIN-rail; fanless convection cooling for quieter and low-maintenance operation.

  • Protection class: IP20, ambient operating temperature −20 °C to +70 °C.

  • Worldwide approvals and global mains compatibility thanks to wide-input and international approval package.

Technical Specifications (Key Data):

Parameter Specification
Nominal Input Voltage 100 V AC … 240 V AC
Input Voltage Range 85 V AC … 264 V AC; also 120 V DC … 375 V DC
Output Voltage 24 V DC ±2%
Output Current 20 A
Output Power 480 W
Efficiency Approx. 85% (115 V AC), 88% (230 V AC)
Dimensions (W × H × D) 85.5 mm × 123.6 mm × 128.5 mm
Protection Degree IP20
Ambient Operating Temp. –20 °C … +70 °C

Applications & Use-Cases:
This power supply is ideal for industrial automation panels, machine-tool control cabinets, conveyor systems, or any equipment requiring a stable and high-capacity 24 V DC supply from a single-phase mains source. Its 480 W capacity makes it suited for higher-load applications where reliability and robust mounting are essential.

Why Choose This Unit?

  • High power in a DIN-rail form factor.

  • Wide voltage input range for global usage.

  • Fanless, low-maintenance design.

  • Trusted Phoenix Contact quality and industrial approvals.

  • Compact, space-efficient for panel builders.
