Phoenix Contact PS-EE-2G/1AC/12DC/75W/SC – DIN-Rail Power Supply, 12 V DC / 75 W (Single-Phase Input)

Detailed Description:
The Phoenix Contact PS-EE-2G/1AC/12DC/75W/SC (item number 1585280) is a compact, reliable DIN-rail mounted switching power supply from the ESSENTIAL POWER series. It accepts a single-phase AC input (100-240 V AC wide range) and delivers a 12 V DC output at up to 75 W nominal (6.25 A).

Key Features:

• Input: Nominal 100-240 V AC; for full 75 W performance the input range is 110-240 V AC ±10%.

• Output: 12 V DC nominal, with adjustment range 12-15 V DC when within capacity.

• Output current up to 6.25 A (at 75 W).

• High efficiency (~86-87% typical) helping reduce heat and energy waste.

• DIN-rail mountable, compact width (~33 mm) for space-sensitive installations.

• Screw-connection terminals suitable for rigid/flexible wires (0.5-2.5 mm²) for easy installation.

• Designed for industrial ambient conditions: Operating temperature -20 °C to +70 °C (with derating above 45 °C) and IP20 enclosure.

Technical Specification Table:

Applications & Use-Cases:
Ideal for automation panels, building-automation, sensor/actuator supply lines, and any installation that requires a stable 12 V DC rail from a compact, industrial quality DIN-rail power supply. Its narrow form-factor makes it especially suitable when panel space is at a premium.

Why Choose This Model?

• Delivers 12 V DC 75 W in a compact, DIN-rail form factor.

• Wide input voltage range supports global installation and varying mains conditions.

• Efficiency and quality make it cost-effective while maintaining industrial reliability.

• From a trusted brand (Phoenix Contact) with a strong reputation in control-panel components.
