Phoenix Contact PS-EE-2G/1AC/24DC/120W/SC – DIN-Rail Power Supply Unit 24 V DC / 120 W (Single-Phase Input)

Phoenix Contact PS-EE-2G/1AC/24DC/120W/SC – DIN-Rail Power Supply Unit 24 V DC / 120 W (Single-Phase Input)

GH₵1,120.00
GH₵1,200.00 GH₵1,120.00
Sale Sold out

Detailed Description:
The Phoenix Contact PS-EE-2G/1AC/24DC/120W/SC (item number 1234302) is a compact, robust switching power supply designed for DIN-rail mounting in industrial control panels and automation systems. It provides a reliable 24 V DC output at up to 5 A (120 W) from a universal single-phase mains input, making it ideal for global installation and versatile usage.

Key Features:

  • Universal AC input: 100–240 V AC nominal (110–240 V typical) enabling worldwide deployment.

  • Output: 24 V DC nominal; adjustable from 24 V … 28 V DC when load permits. Nominal output current: 5 A (i.e., 120 W). High efficiency: ~87 % (at 120 V AC) and ~88 % (at 230 V AC) helps reduce heat in panel installations.

  • Mounting: DIN-rail (standard TH35 rail) with screw-terminal connection for secure wiring.

  • Output protections: short-circuit proof and no-load proof design ensures durability under adverse conditions.

  • Designed for industrial ambient conditions: wide mains frequency (50-60 Hz), robust surge-protection using varistor.

Technical Specifications:

Parameter Specification
Input Voltage (nominal) 100 V AC … 240 V AC
Input Voltage Range 110 V AC … 240 V AC ±10 % (for full 120 W)
Frequency Range 50 Hz … 60 Hz ±10 %
Output Voltage 24 V DC nominal
Output Adjustment Range 24 V … 28 V DC (when permitted)
Output Current (Nominal) 5 A (120 W)
Efficiency ~87% (120 V AC) / ~88% (230 V AC)
Protections Short circuit proof, no-load proof
Mounting / Connection DIN-rail with screw terminals
Protection Rating IP20

Applications & Use-Cases:
Ideal for automation control cabinets, machine tools, conveyor systems, building-automation power rails, and anywhere you need a dependable 24 V DC supply from single-phase mains. Compact width makes it suitable for panel installations with limited space. Its adjustable output voltage makes it flexible for specialised loads or integration into system redundancy or series/parallel configurations.

Why Choose This Unit?

  • Global input range simplifies procurement and deployment across regions.

  • Compact DIN-rail format for easy integration into industrial cabinets.

  • Proven reliability with Phoenix Contact’s ESSENTIAL POWER line — tailored for cost-sensitive yet industrial-capable applications.

  • Low-maintenance design thanks to fanless operation and high efficiency, meaning less heat and longer component life.
