Phoenix Contact SAC-5P-M12MS/1,5-PUR Sensor/Actuator Cable – 5-Pole A-Coded M12 Male Plug to Free Cable End, Halogen-Free PUR Jacket, 1.5 m

Detailed Description:

The Phoenix Contact SAC-5P-M12MS/1,5-PUR (Item No. 1669767) is a high-performance sensor/actuator cable engineered for industrial automation and control systems requiring robust, reliable connectivity. The assembly offers a straight M12 male plug configured in 5-pole A-coding on one end, and a free cable end on the other — enabling flexible termination in your system. Its length is 1.5 metres, making it ideal for moderate-reach connections without excess slack.

Key Features & Benefits:
• 5-pole A-coded interface — Compatible with field sensors, actuators and modules using standard M12 A-coding.

• Halogen-free PUR jacket — The outer sheath is made from halogen-free polyurethane material, black-grey RAL 7021, delivering excellent mechanical, chemical and environmental resistance (abrasion, oil, solvents, UV partial) for harsh industrial environments.
• Robust construction & specs —

• Conductor cross-section: 5 × 0.34 mm² (AWG 22) signal lines.

• Outer cable diameter: approx. 4.55 mm ±0.15 mm.

• Nominal current: 4 A.

• Rated voltage: 48 V AC / 60 V DC for the connector side; cable rated up to 300 V test voltage.

•
  • High durability for dynamic use — The cable supports up to 10 million bending cycles in fixed applications and ≥ 2 million torsion cycles in traversing installations (46 mm bending radius, 10 m traversing path @3 m/s) — ideal for moving machinery, conveyors or robotic cells.

•
  • Ingress protection & extreme environment rating — The connectors meet IP65 / IP67 / IP68 ratings (depending on mating part) and the cable works in ambient temperatures from –40 °C up to +80 °C (fixed installation) and –25 °C up to +80 °C (flexible installation). For plug/socket interface the rating extends to –25 °C … +90 °C.

Typical Applications:
This cable is perfect for high-reliability wiring in production machinery, factory automation, assembly lines, robotics, packaging systems, AGVs (automated guided vehicles), control cabinet installations and other demanding environments where signal integrity and durability are crucial.

Installation & Use Notes:

• Ensure that the mating connector is a 5-pole, A-coded M12 female receptacle for correct compatibility.

• Route the cable so that the minimum bend radius (≈ 10× outer diameter ≈ 45–50 mm) is respected, especially in dynamic or flexible installations.

• Tighten the M12 connector to the recommended torque of 0.4 Nm.

• Given the free cable end, care should be taken during termination to maintain shielding (where applicable) and strain relief to preserve cable integrity.

Scope of Delivery:
One (1) cable assembly, 1.5 metres in length, with straight M12 male plug (5-pole, A-coding) on one end and free, unterminated cable end on the other, jacketed in halogen-free PUR.

Manufacturer / Item Number: Phoenix Contact, Item No. 1669767.

Summary:
If you require a ready-to-install, durable 5-pole sensor/actuator cable with a free cable end — particularly for high-stress or mobile automation installations — the Phoenix Contact SAC-5P-M12MS/1,5-PUR (1669767) delivers top-tier performance, excellent build quality and compatibility with M12 industrial connector systems.
