UNO MDR-100-24 – 24V 4A DIN Rail Power Supply

Output Power: 96W Output Voltage: 24V DC Current: 4A
Mounting: DIN rail (TS-35/7.5 or 15) Enclosure: Plastic case

Key Specifications:

• Input Voltage: 85–264V AC / 120–370V DC
• Output Voltage: 24V DC (adjustable 24–30V)
• Efficiency: Up to 86%
• Ripple & Noise: ≤ 150mVp-p
• Protection Features:
• Overload (105–150%, constant current limiting)
• Overvoltage (31.2–36V, shutdown mode)
• Over temperature (shutdown, auto-recovery)
• Short circuit (auto recovery)
• Operating Temperature: -10°C to +60°C (derating above 45°C)
• Dimensions: 55 × 90 × 100mm (W × H × D)
• Certifications: UL508, EN62368-1, CE, RoHS
• MTBF: > 2.2 million hours (Telcordia SR-332)

Features:

• LED indicator for DC OK status
• Fully enclosed plastic housing with Class II insulation
• Built-in EMI filter and surge protection
• DC OK relay contact (30V/1A resistive)
• Complies with heavy industrial EMC standards

Applications:

• PLC and sensor power supply
• Industrial automation and control systems
• Building management and HVAC
• Security and access control systems
