UNO MDR-60-24 – 24V 2.5A DIN Rail Power Supply

Output Power: 60W Output Voltage: 24V DC Current: 2.5A
Mounting: DIN rail (TS-35/7.5 or 15) Enclosure: Plastic case

Key Specifications:

• Input Voltage: 85–264V AC / 120–370V DC
• Output Voltage: 24V DC (adjustable 24–30V)
• Efficiency: Up to 88%
• Ripple & Noise: ≤ 150mVp-p
• Protection Features:
• Overload (105–150%, constant current limiting)
• Overvoltage (31.2–36V, shutdown mode)
• Short circuit (auto recovery)
• Operating Temperature: -20°C to +70°C (derating above 50°C)
• Dimensions: 40 × 90 × 100mm
• Certifications: UL508, EN62368-1, CE, RoHS
• MTBF: > 2.3 million hours (Telcordia SR-332)

Features:

• LED indicator for DC OK status
• Fully enclosed plastic housing with Class II insulation
• Built-in EMI filter and surge protection
• No-load power consumption <0.75W
• Complies with heavy industrial EMC standards

Applications:

• PLC and sensor power supply
• Industrial automation and control systems
• Building management and HVAC
• Security and access control systems
