UNO RT-50D – 5V / 24V / 12V Triple Output Power Supply

Output Power: 51W Outputs: 5V @ 3A, 24V @ 1A, 12V @ 1A
Mounting: Chassis mount Enclosure: Metal case

Key Specifications:

• Input Voltage: 88–264V AC / 125–373V DC
• Efficiency: Up to 78%
• Ripple & Noise:
• 5V: ≤ 80mVp-p
• 24V: ≤ 150mVp-p
• 12V: ≤ 120mVp-p
• Protection Features:
• Overload (110–150%, hiccup mode)
• Overvoltage (CH1: 5.75–6.75V)
• Short circuit
• Operating Temperature: -25°C to +70°C (derating above 50°C)
• Dimensions: 99 × 97 × 36mm
• Certifications: UL, CE, TUV, RoHS
• MTBF: > 169,000 hours (MIL-HDBK-217F, 25°C)

Applications:

• Embedded control systems
• PLC and sensor power supply
• LED lighting and signage
• Security and access control systems
