YX5120 – Time Delay Relay (AC220V, 16A)

Rated Voltage: 220V AC Rated Current: 16A
Mounting: Plug-in base (typically 8-pin)
Output Type: DPDT (2 Form C) relay contact
Timing Function: ON-delay (Power ON start)

Key Specifications:

• Time Range Options:
  1s, 3s, 6s, 10s, 30s, 60s
  3min, 6min, 10min, 30min, 60min
  3h, 6h, 10h, 30h (model-dependent)
• Reset Time: ≤0.1s
• Repeat Accuracy: ±1%
• Setting Error: ±10% ±0.05s
• Operating Temperature: -10°C to +55°C
• Indicators: LED for power and output status
• Enclosure: DIN 48 × 48 mm housing
• Socket Compatibility: P3G-08 or similar 8-pin base

Features:

• Rotary dial for precise time setting
• LED indicators for visual feedback
• Flame-retardant housing with clear markings
• Long mechanical life: ≥5 million operations
• High current capacity for demanding loads

Applications:

• Conveyor and motor delay control
• Lighting and HVAC sequencing
• Process timing in automation panels
• Safety interlocks and alarms
